PV Input

Max. PV Input Power:  1000W

Max. DC Input Voltage:  100Vdc

Max. Input Current:  18A

MPPT Voltage Range:  20V-100V

AC Input

Nominal Operating Voltage:  230Vac

Nominal Operating Frequency:  50/60Hz

Max.Input Current:  8A

AC Output

Rated Output Power:  1200VA/1200W

Nominal AC Output Voltage:  208/220/230/240Vac

Nominal AC Frequency:  50/60Hz

Surge Power(3 seconds):  1400VA/10min

Nominal AC Output Current:  5.5A

Battery

Rated Voltage:  12Vdc

Max. PV Charging Current:  60A

Max. AC Charging Current:  60A

Max. Battery Discharging Current:  120A
